Short Description

Subminiature IP67 waterproof 2A 12V DC micro switch for sale, welcome to contact us to buy the switch. As a manufacturer supplier, you can get what you want.

  • MQS-4 Waterproof Micro Switch

  • Product name: MQS-421BK00

  • Product applications:Smart homes such as multi-function telephones, large-scale mixing consoles, household gas appliances, washing machines, dishwashers, etc.; new energy vehicle charging guns, car air conditioning controllers, car door locks, car sensors, and other automotive markets.

SEND EMAIL TO US
DOWNLOAD AS PDF

Details Description

Subminiature IP67 waterproof 2A 12V DC micro switch for sale, welcome to contact us to buy the switch. As a manufacturer supplier, you can get what you want.
Toneluck MQS-421BK00 is an SPDT sealed structure miniature switch so that it is waterproof with IP67 except for the switch terminal. Meanwhile, it is also has a long service life of mechanical cycles. For example, the mechanical life for this item is 1 000 000 cycle and the electrical cycles are 100000 cycles in 2A 12VDC while are 50000 cycles in 4A 24VDC.

Specification

Model No. MQS-421BK00
Operating Temperature -40℃ to +85℃
Rating 2A 12VDC 100,000 cycles Min.

2A 24VDC  50000 cycles Min.

Mechanical Life 500,000 cycles Min.
Insulation Resistance 100ΩM Min.
Dielectric Strength 1000VAC for 60 ± 5 sec.
Housing UL 94V-0 Thermoplastic
Contact Silver
Operation Force (OP) 200gf Max.
Release Force (RP) 50gf Min.
Pre-Travel (PT) 1.2mm Max.
Movement-Differential (DT) 0.4mm Max.
Operation Position (OP) 9.4±0.3 mm
Free Position(FP) 10.4mm Max.
