Short Description

Toneluck D6 Dryer Door Switch is an SPDT 10A switch used in dryers, washing machines, and other home appliances for Whirlpool, GE, Samsung, etc. Besides, we can provide OEM and ODM solutions with engineering support for our customers.

  • D6 series door switch

  • Product name: D611M-DA1-1

  • Product applications: Smart home appliances such as washing machines, refrigerators, dishwashers, air conditioners and so on.

SEND EMAIL TO US
DOWNLOAD AS PDF

Details Description

Toneluck D6 door switch is an SPDT 10A switch used in dryers, washing machines, and other home appliances for Whirlpool, GE, Samsung, etc. Meanwhile, the switch has the certification of UL, ENEC, and CQC. So it can ensure the product quality. The rating of UL is 16GPA 125/250VAC;1/3HP 125/250VAC;3/4HP 125/250VAC;0.4RA 250VDC with 6,000cycles. And, the rating of ENEC & CQC is 10(4)A 125/250VAC with 5,0000 cycles.

Specification

Electrical Rating 10~50mA 12~24 VDC 250,000 cycles Min.
Operating Temp -40℃ to +85℃
Mechanical Life 500,000 cycles Min.
Contact Resistance 50mΩ Max. (initial)
Operating Force 150gf Max.
Insulation Resistance 100ΩM Min.
Dielectric Strength 500VAC for 60 ± 5 sec.
Housing: UL 94 HB Thermoplastic (Base)
UL 94 HB Thermoplastic (Cover)
