Door Switch for Microwave Short Description
This is a door switch for the microwave oven, which is also called a microswitch to activate the light inside when the microwave opens. So we need to use the NC type, which generally is 16A 110-250VAC.
MQS-2 Switches Series
Product name: MQS-216TN00BBM-01
Product applications: Smart homes such as multi-function telephones, large-scale mixing consoles, household gas appliances, washing machines, dishwashers, etc.; new energy vehicle charging guns, car air conditioning controllers, car door locks, car sensors, and other automotive markets.
Details Description
This is a door switch for the microwave oven, which is also called a microswitch. It is used to activate the light inside when the microwave opens. So we need to use the NC type, which is 16A 110-250VAC generally. In fact, the operation force is not so important for the microwave. But, the different applications are required different parameters, this switch is not only suitable for it but also suitable for other products.
So, if you have any questions, please feel free to contact us. We will reply to you and solve the problem.
Specification
| Model No. | MQS-216TN00BBM-01 |
| Operating Temperature | -40℃ to +125℃/ 40 T 125 |
| Rating | 16A 125/250VAC, 1/2HP 125VAC, 3/4HP 250VAC |
| Mechanical Life | 1000,000 cycles Min. |
| Insulation Resistance | 100ΩM Min. |
| Dielectric Strength | 1000VAC for 60 ± 5 sec. |
| Housing | UL 94V-0 Thermoplastic |
| Contact | Silver |
| Lever Type | Without Lever |
| Operation Force (OP) | 160±30gf |
| Release Force (RP) | 50gf Min. |
| Pre-Travel (PT) | 1.2mm Max. |
| Over- Travel (OT) | 1.25mm Min. |
| Movement-Differential (DT) | 0.4mm Max. |
| Operation Position (OP) | 14.7±0.5 mm |
